Due 10/11/24
Car Parking Hoist – 4.5 Ton Triple Stacker
Pre-Order
$19,999 (inc. GST)
Available on back-order
Overview
Dimensions suit shed/ factory use | Single phase 240v motor as standard | Perfect for long term car storage | Will lift most vehicles with ease | Minimum 5.4 metre ceiling height required |
Car Parking Hoist Features
- 4500kg/ 4.5 ton overall safe load limit
- Ground unlimited, middle platform 2500kg & top platform 2000kg capacity
- Overlap platform design
- Dust & oil protection covers
- Clearance heights of 1.65m/ 1.6m/ 1.65m+
- Keep your cars off the ground away from being dented, scratched and touched
- Durable powder coated finish
- 4 metre per minute (no-load) travel speed
Safety Features
- Emergency stop
- Self-restore key switch
- Full size dynamic anti-fall lock
- Safety brake
- 24v electronic control system
- Power overload protection
- Limit switch
- 10mm steel wire rope lifting cables
- Anti-surge valve in the hydraulic power unit
What’s Included?
- Car parking hoist with all bolts, cables, lines and fixings
- 240V single phase hydraulic power unit
- Concrete anchor bolts
- Detailed installation instructions
What’s Not Included?
- Hydraulic oil
- Setup of power units electrical connection
Shed Requirements
- 200mm deep concrete at 32mpa with 500 x 500mm x 300mm deep footings under each column
- Minimum ceiling height of 5.4m
Warranty & Certifications
- 3 year Australian warranty* includes structure, hydraulics & electrics
- Independent Australian Standards certified
- CE certification
Car Parking Hoist Warranty
When you purchase a car hoist from us you can guarantee that you are investing in a quality product with the support to match it.
Our Car Parking Hoists come with 3 years warranty* for complete peace of mind.
* Joel’s Garage Gear offers 3 years parts only warranty on all car hoists. Warranty claims do not cover incorrect use or installation. See our Terms & Conditions for more information.
I have just had a Joels 4.5t hoist installed in my garage. Hoist is really great quality, delivered on time as agreed. installed the same day by ann absolute professional. The installer gave me a safety run thorough and a minor maintenance/care run through as wellAbsolutely professionally supplied, installed and great quality As an engineer myself I highly recommend Joel’s Garage for your business or private workshop needs. Nicely done Joel’s garage
I Recently purchased a narrow , 3T , 4 poste hoist and air jacking beam from Joel's Garage gear. The product is great. Service and sales process was easy and friendly. I had a call from Andrew in regards to a small issue I encountered. Overall a great product.
Awesome serviceHad a problem with a damaged piece rang them up and they replaced it straight away and delivered it to my door.This is hoist number 2 for me now.Cannot recommend these guys enough.
Very good team to deal with, ordering was a breeze. Pick up was easy. Good quality product, instructions were not the best very small print. I got the motorcycle lift with the only bug I had was my Breakout is so low that I needed shoring on the ramp so my bike doesn’t scrape the mainframe when putting it on/off the platform.
Awesome process, easy ordering and delivery was smack on time. The garage storage cabinets speak for themselves excellent quality. ILL BE BACK.
Great to deal with, one stop shop bought the hoist Joel's staff arranged for fitment. It was picked up and fitted hassle free. I also bought a couple of other items very happy. Thanks guys.
Couldn't be happier with recent purchase of this cabinet set-up. After looking around and pricing up various options, these really stood out. They arrived in 2 days from ordering! Well packaged with lots of foam and cardboard, easy to put together, adjustable shelves, legs and all bolted together easily. Magnet close and keyed locks is great. Very well built and look awesome. We added a metal peg board and power point in workbench space and finished it off nicely.
It’s a great unit. Drawers feel nice opening and closing. Was well packed and arrived really quickly. And as a Zappa fan of old, it’s just a little giggle to see Joel’s logo on my beautiful toolbox.
Excellent quality tool trolley. Great value for money. Excellent workmanship. Highly recommend this tool trolley. Delivery was quick and easy to pickup. Look no further. This is the tool trolley for everyone.
The boys at the pickup location had excellent communication for a smooth pickup transaction. Their bead roller works great and is really heavy duty and robust
Will have to say was good dealing with Joel's garage in sales and delivery, they are people of there word very happy with the product of a two post hoist
Quality hoist at a fabulous price and expert installation. I couldn’t be happier. A must have for an shed or garage!
Got my 2 post hoist installed today, all went very smoothly, hoist is good quality, can highly recommend!
I am a hoist installer.I first installed a Joels Garage Gear 4 ton 2 post hoist a few years ago. My customer had purchased the hoist online. I had not heard of Joels.The hoist was solid and seemed quite good quality.I have since installed more Joels Garage Gear Hoists. Several 2 post hoists and a 4 post hoist. The quality is impressive. They are obviously committed to great product development as I can see improvement in quality and design.I have now applied to become one of their registered Hoist Installers.
Absolute pleasure to deal with, kept me informed on the progress all the way to delivery. Highly recommended to use this company. Will always recommend to my friends. Thanks for the great service Ron
These guys were great to deal with, hoist arrived promptly and before due date, after sale's information very helpful, and to top it all off the product is fantastic. HIGHLY recommend Joel's
On time delivery, excellent hoist and fair price, easy to assemble, 2.7m clearance between posts is great.
My original thoughts were to buy a 4 post hoist but because of limited space I opted for the 2 poster from Joels Garage. So glad I did because it's so versatile, especially when my boat needs separating from it's trailer. With over 60 years experience in engineering I find the design and robust construction of my hoist is second to none and can certainly recommend it to prospective buyers. My only gripe is the vague instruction manual and lack of detail.
Flexible Payment Options Available
Dimensions
| MOTOR | 240V 20A SINGLE PHASE |
| HOIST DIMENSIONS | |
| Overall Width | 2802MM |
| Overall Length | 5060MM |
| Overall Height | 4216MM |
| LOAD CAPACITY | |
| Top Platform | 2000KG |
| Middle Platform | 2500KG |
| CLEARANCE BETWEEN POSTS | 2492MM |
| USABLE WHEEL TRACK WIDTH | |
| Top Platform | 2200MM |
| Under Platforms | 2100MM |
| MINIMUM CONCRETE THICKNESS | 200MM SLAB & 500MM X 500MM X 300MM DEEP FOOTINGS |
Material Thickness
| CABLES | 10MM |
| CROSS BEAMS | 4MM |
| RUNWAYS | 5MM |
| COLUMNS | 5MM |
Freight Information
| HOIST | L: 490CM | W: 72CM | H: 115CM |
| WEIGHT | 2200KG | ||
| MOTOR | L: 100CM | W: 60CM | H: 50CM |
| WEIGHT | 120KG | ||
| TOTAL WEIGHT | 2320KG |
